The Blustream SC12SP-V2 is a 4K HDMI 2.0 splitter with in-built scaler, designed for installations in which a single 4K video source needs to be distributed to multiple displays that support different maximum video resolutions. The SC12SP-V2 supports down-scaling of up to 4K 60Hz 4:4:4 video to various lower resolution video formats. The SC12SP-V2 also includes audio breakout, advanced EDID management and supports HDCP 2.2.
Key Features:
- Features 1x HDMI input that is replicated to 2x HDMI outputs
- Supports HDMI 2.0 18 Gbps specification including HDR
- Supports up to 4K UHD 60Hz 4:4:4
- HDMI output 2 supports 4K UHD video pass-through
- HDMI output 1 will down-scale the video input to the following formats:
- - 1080P@ 24/25/30/50/60Hz (for screens that do not support 4K)
- - 4K 50/60Hz 4:2:0 (for screens that do not support full 4K 60Hz 4:4:4)
- Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD
- Master Audio transmission
- HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
- Advanced EDID management
- HDCP 2.2 support
